Incoloy 800 Tubes, ASTM B163 Incoloy 800 Tubes, ASME SB163 Incoloy 800 Tubes, ASTM B163 UNS NO8800 Tubes, Incoloy 800 Seamless Tubes, Incoloy 800 Seamless Tubing.
Manufacturing Incoloy Tube 800 / Incoloy 800H / Incoloy 800HT / Incoloy 825 / UNS NO8800 / UNS NO8810 / UNS NO8811 / UNS NO8825 Tube, BIS Approved Dealer, Distributor, Exporter, Supplier in India.
ASTM B163 is a standard specification established by ASTM International, formerly known as the American Society for Testing and Materials. This specification covers seamless nickel and nickel alloy Incoloy tubes for general corrosion-resistant and heat-resistant applications. Incoloy is a family of superalloys that are predominantly composed of nickel, with the addition of various alloying elements like chromium, iron, and other metals to enhance their properties.
The ASTM B163 specification is particularly important for industries and applications where resistance to high temperatures, aggressive chemicals, and corrosion is essential. Incoloy tubes manufactured in accordance with ASTM B163 are known for their exceptional performance and reliability in such challenging environments.
Valour Alloy Inc., we carry a full inventory of ASTM B163 Incoloy Tube products is a a nickel-molybdenum-chromium superalloy with an addition of tungsten designed to have excellent corrosion resistance in a wide range of severe environments. This nickel alloy is resistant to the formation of grain boundary precipitates in the weld heat-affected zone, thus making it suitable for most chemical process application in an as welded condition.
Valour Alloy specializes in ASTM B163 Incoloy Tube. we offer high quality, lower cost but the best service. As a result to that our ASTM B163 Incoloy Tube export account today is in various countries like Iran, Iraq, Kuwait, Saudi Arabia, Oman, UAE, Singapore, Malaysia, Indonesia, South korea, Chile, Peru, Venezuela, Australia, Nigeria, Angola, Senegal, Mozambique, Algeria, Libya, Azerbaijan, Netherlands, Brazil, Norway, United Kingdom, Mexico, Canada etc.
ASTM B163 Incoloy Seamless Tube
ASTM B163 Incoloy Welded Tube
We Supply INCOLOY 800, 800H, 800HT, 825 Tubes in ASTM B163, ASTM B407, ASTM B423, The grade indicates the testing methods required for a given application.
Prime quality Incoloy Alloy 800 Instrumentation Tube suppliers, Incoloy 800H Heat Exchanger Tube manufacturers, Check Incoloy 800HT Cold Rolled Coiled Tubing Price List, Incoloy 825 Polish Tube importer in India, ASTM B163 Incoloy Tubing suppliers in Mumbai
Material Composition: Incoloy tubes under ASTM B163 are typically made from nickel-based alloys, with Incoloy 800 and Incoloy 825 being common examples. These alloys contain varying percentages of nickel, chromium, iron, and other elements to provide superior resistance to corrosion and high-temperature conditions.
Seamless Construction: ASTM B163 specifies seamless manufacturing processes for Incoloy tubes. Seamless tubes are known for their uniformity, strength, and resistance to leakage, making them suitable for high-pressure and critical applications.
Corrosion Resistance: Incoloy tubes conforming to ASTM B163 exhibit excellent corrosion resistance, even in aggressive environments such as sulfuric acid, nitric acid, and chloride-containing solutions. This corrosion resistance is essential for industries like chemical processing, petrochemicals, and power generation.
Heat Resistance: These tubes are designed to withstand high temperatures without deformation or degradation of their mechanical properties. This heat resistance makes them ideal for applications like heat exchangers, furnaces, and thermal processing equipment.
Quality Standards: Incoloy tubes manufactured in accordance with ASTM B163 must meet strict quality control and testing standards to ensure their reliability and performance. This includes dimensional checks, mechanical property tests, and non-destructive testing methods.
ASTM B163 Incoloy tubes are essential components in industries where resistance to corrosion and high temperatures is paramount. Their seamless construction, excellent material properties, and adherence to strict quality standards make them reliable choices for a wide range of critical applications.
ASTM B163 800, 800H 800HT Incoloy Tube Range
| ASTM B163 Incoloy Tube Outer Diameter Size | Seamless - 1/4" NB To 6" NB (Nominal Bore Size) Welded / ERW- 1" NB To 16" NB (Nominal Bore Size) |
| ASTM B163 Incoloy Tube Wall Thickness | Schedule 10 To Schedule 160 |
| ASTM B163 Incoloy Tube Length | 5 To 7 Meters, 09 To 13 Meters, Single Random Length, Double Random Length And Customize Size. |
| ASTM B163 Incoloy Tube Ends | Plain Ends / Beveled Ends |
| ASTM B163 Incoloy Tube Specification | ASTM B163 / ASTM B407 / ASTM B423 / ASME SB163 / ASME SB407 / ASME SB423 |
| ASTM B163 Incoloy Tube Grades | INCOLOY 800 / INCOLOY 800H / INCOLOY 800HT / INCOLOY 825 / UNS NO8800 / UNS NO8810 / UNS NO8811 / UNS NO8825 |
| ASTM B163 Incoloy Tube Dimension | All Tubes Is Manufactured and Inspected / Tested to the Relevant standards including ASTM and ASME |
| ASTM B163 Incoloy Tube Type | Cold Drawn Seamless / Welded / ERW |
| ASTM B163 Incoloy Tube Delivery Conditions | As Rolled, Cold Drawn, Hot Finish, Stress Relieved, Annealed, Hardened, Tempered |
| ASTM B163 Incoloy Tube Coating | Electropolish, Mechanical Polish, Satin Finish, Passivated |
| ASTM B163 Incoloy Tube Machinery | Draw Bench / Pilger / De-Coiler / Edge Miller / Welding Line / Heat Treatmen Furnace / Pickling Tank / Cutting Bench etc. |
| ASTM B163 Incoloy Tube Value Added Services | Draw / Expansion / Machining / Sand Blasting / Shot Blasting / Heat Treatment |
| ASTM B163 Incoloy Tube Packaging | Loose / Bundle / Wooden Pallet / Wooden Box / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector |
| ASTM B163 Incoloy Tube Shipment & Transportation | By Road - Truck / Train, By Sea - Break-bulk Conventional Vessel / FCL (Full Container Load) / LCL (Less Container Load) / 20 Feet Container / 40 Feet Container / 45 Feet Container / High Cube Container / Open Top Container, By Air - Freighter Civil Passenger and Cargo Planes |
| ASTM B163 Incoloy Tube Other Testing | NACE MRO175, Hardness Test, Flare, Hydrostatic Test, Eddy Current test, Grain Size Test, Eddy Current, Annealed, Tempered, Stress Relieved etc. |
| ASTM B163 Incoloy Tube Material Test Certificate | Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS ETC. |
Chemical Composition & Mechanical Properties of ASTM B163 800, 800H 800HT Incoloy Tube
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Inconel Alloy 800 Tube | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Inconel Alloy 800H Tube | 0.05 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Inconel Alloy 800HT Tube | 0.06 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60ᴬ | 0.15 – 0.60ᴬ |
Mechanical Properties of ASTM B163 800, 800H 800HT Incoloy Tube
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 800 / 800H / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
Equivalent Grade of ASTM B163 800, 800H 800HT Incoloy Tube
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN | OR |
| Tube Incoloy 800 Equivalent | 1.4876 | N08800 | NCF 800 | NA 15 | ЭИ670 | Z8NC32-21 | X10NiCrAlTi32-20 | XH32T |
| Tube Incoloy 800H Equivalent | 1.4958 / 1.4876 | N08810 | NCF 800H | NA 15(H) | ЭИ670 | Z8NC33-21 | X5NiCrAlTi31-20 | XH32T |
| Tube Incoloy 800HT Equivalent | 1.4859 / 1.4876 | N08811 | NCF 800HT | NA 15(HT) | ЭИ670 | – | X8NiCrAlTi32-21 | XH32T |
Other Available Products of ASTM B163 800, 800H 800HT Incoloy Tube
| Incoloy 800 Seamless Tubes | 800 Incoloy EFW Tubing Stockiest in India |
| 800H Incoloy Seamless Tubing | Incoloy JIS SUS Cold Rolled Coiled Tubing |
| ASTM B515 Incoloy Welded Tubes | ASME SB163 Incoloy 800H Tubing |
| B358 Incoloy Welded Tubes Suppliers | 825 Austenitic Incoloy Tubing |
| ASTM B407 Incoloy 800HT ERW Tubes Manufacturer | 800HT Incoloy LSAW Tubes Dealers |
| B163 Rectangular Seamless Tubing Manufacturer | ASTM B358 Inconel Capillary Tube |
| 825 Incoloy Rectangular Tubes | Incoloy 825 U Shaped Tubing Stockholder |
| Incoloy 800 ERW Tubes Distributors | 800 Incoloy Hydraulic Tubes Suppliers |
| UNS N08800 Incoloy Coiled Seamless Tubing | Inconel Electric Resistance Welding Tubes Suppliers |
| Top Quality Incoloy 800H Heat Ex-changer Tubes | 800HT Incoloy ASME SB515 Welded Tubing |
| Incoloy 825 DIN 1.4876 Round Tubing Exporter | Inconel ASME SB407 Seamless Tubing |
| ASTM B515 Inconel Square Seamless Tubes | 800 Inconel ASME SB358 Welded Tubes Exporter |
| ASME SB407 Incoloy Electric Fusion Welding Tubes | Inconel 800H Instrumentation Tubes Exporter |
ASTM B163 800, 800H 800HT Incoloy Tube Application
- Oil and Gas equipments
- Offshore Technology
- Seawater Desalination Plants
- Chemical Industry
- Airport, Malls, Buildings
- Storage Tanks
- Medical Industry
- Civil Engineering
- Pressure vessels, Reactor tanks, and Heat exchangers
- Rotors, impellers and shafts
- Power Plants
- Petrochemical
- Shipbuilding Industry
- Mining Industry
- Food Equipments Industry
Test Certificates
We ASTM B163 Incoloy Tube with the following details Mill Test Certificate according to EN 10204 3.1, PMI Test, Test Report from NABL Approved Lab, 3.2 Certification by External Testing Authority third, ultrasonic test report, and X-ray report.
Quality Assurance
At Valour Alloys all types of ASTM B163 Incoloy Tube such as Incoloy Welded Tube, Incoloy 800 UNS N08800 Square Tube, Nickel Alloy 800 Exhaust Tubing, Alloy 800 Gas Tube from raw material purchase to production and product shipping. They are visually inspected for compliance with ASTM, ASME, DIN, EN and JIS codes and standards. We can also designate certified official testing agencies upon customer request so that they can witness the product's material, size and quality compliance reports.
Marking & Packing
Our ASTM B163 Incoloy Tube is packaged to ensure no damage during transit. In the case of export, the standard export packing is in a wooden box. All ASTM B163 Incoloy Tube are marked with our grade, batch number, size and mark. We can also do custom branding on our products as per buyer's unique requirements
Supplying ASTM B163 800, 800H 800HT Incoloy Tube to Countries -
We Export ASTM B163 800, 800H 800HT Incoloy Tube to Saudi Arabia, Iran, Iraq, United Arab Emirates, Qatar, Bahrain, Oman, Kuwait, Turkey, Egypt, Yemen, Syria, Israel, Jordan, Cyprus, Singapore, Malaysia, Indonesia, Thailand, Vietnam, South Korea, Japan, Sri Lanka, Maldives, Bangladesh, Mayanmar, Taiwan, Cambodia, Argentina, Bolivia, Brazil, Chile, Venezuela, Colombia, Ecuador, Guyana, Paraguay, Uruguay, United States of America, Canada, Mexico, Panama, Costa Rica, Puerto Rica, Trinidad And Tobago, Jamaica, Bahamas, Denmark, Russia, Norway, Germany, France, Italy, United Kingdom, Spain, Ukraine, Netherland, Belgium, Greece, Czech Republic, Portugal, Hungary, Albania, Austria, Switzerland, Slovakia, Finland, Ireland, Croatia, Slovenia, Malta, Nigeria, Algeria, Angola, South Africa, Libya, Egypt, Sudan, Equatorial Guinea, The Republic Of Congo, Gabon, Europe, Africa, Asia, North America, South America, Middle East, Far East Etc.
Distributing ASTM B163 800, 800H 800HT Incoloy Tube to Cities -
We Export ASTM B163 800, 800H 800HT Incoloy Tube to Navi Mumbai, Indore, Baroda, Muscat, Secunderabad, Gimhae-si, Kanpur, Colombo, Kuala Lumpur, Bhopal, Pimpri-Chinchwad, Rajkot, Haryana, Hanoi, Ernakulam, Chandigarh, Surat, Los Angeles, Hong Kong, Ahmedabad, Perth, Petaling Jaya, Hyderabad, Mumbai, Algiers, Edmonton, Ludhiana, Ho Chi Minh City, Karachi, Bangkok, Dallas, Bengaluru, Jakarta, Granada, Seoul, Cairo, Geoje-si, Rio de Janeiro, Abu Dhabi, Port-of-Spain, Sydney, London, Courbevoie, Vung Tau, Sharjah, Jaipur, Lahore, Chennai, Istanbul, Lagos, Thane, Dubai, Coimbatore, La Victoria, Calgary, Jeddah, Busan, Mexico City, Al Khobar, Caracas, Singapore, Atyrau, Manama, Kolkata, Riyadh, Jamshedpur, Brisbane, Toronto, Noida, Ahvaz, Vadodara, Doha, Visakhapatnam, Ulsan, New Delhi, Gurgaon, Bogota, Howrah, Moscow, Nashik, Ranchi, Nagpur, Al Jubail, Houston, Milan, Chiyoda, Aberdeen, Melbourne, New York, Dammam, Montreal, Santiago, Kuwait City, Pune, Tehran, Thiruvananthapuram, Faridabad, Madrid, Ankara Etc.
